Specification / Features on Tracer VIII Ultra I16U Series

Features:

• 14th Generation Intel® Raptor Lake-HX Refresh Processor

• High Performance NVIDIA® GeForce® RTX 40 Series Graphics

• Standard with Premium Cooling System for CPU and GPU + Liquid cooling Optional

Processor • Intel® Core™ Processor i9-14900HX 8P/16 + 16E Max Turbo 5.8GHz 36MB Cache

BIOS • UEFI BIOS support (menu selection)
• ACPI 5.0 compliant
• Support external USB flash memory card boot up
• RPMC ROM

Graphics • NVIDIA® GeForce® RTX 4080 12GB GDDR6

TGP support • Base TGP 175W, Dynamic Boost 25W

Chipset Type • Intel Raptor Lake HM770

LCD Display • 16"16x10 WQXGA - (2560X1600) sRGB100% 240hz LED Display

Web Camera • HD webcam with Digital Microphone support

Memory • (2) SO-DIMM Memory Sockets (Up to 64GB total) DDR5 5600MHz

SSD Storage • 2 Slots (NVMe)
• M.2 2280,
• Slot 1 : NVMe/PCIEX4(Gen4)
• Slot 2 : NVMe/PCIEX4(Gen4)
• RAID 0/1 support

LAN • Supports 10/100/1000/2500 Mb/sec

WLAN • Intel WIFI6E AX211, IEEE802.11 a/b/g/n/ac/ax support

I/O Port • USB-A (USB3.2 Gen1 x1, 5Gbps)@Right x2
• USB-A (USB3.2 Gen1 x1, 5Gbps)@Left x1 w/ bc 1.2 protocol supported
• USB-C (USB3.2 Gen2, 10Gbps)@Rear x1 w/ PD 100W&TBT4 supported
• USB-C x1 USB3.2 Gen1, 5Gbps @Left x1 w/ bc 1.2 protocol supported

• HDMI 2.1 X1
• RJ45 port X1
• Audio out & Mic in X2
• Liquid cooling connector (Ready) Radiator optional

• 20V 20A Jack＠Rear Side x1
• Kensington lock X1
• SD/SDHC/SDXC, USH-I Full-Size (SDR104:104MB/s)@Right x1

Audio • Smart AMP support
• Nahimic
• Build-in 2 speakers,2W/each
• Digital Microphone support

Keyboard • Membrane RGB backlight Gaming Keyboard

Touch Pad • 121.2*74.9*0.8mm
• Mylar

AC Adapter • 330W:Automatics Voltage adjustment between 100 and 240VAC 50/60Hz, 330 Watts, 3 Pins, 19.5V

Battery • 99.8W 4S1P6450mAh Li- polymer Battery SW Gas Gauge IC, soft pack

Dimensions • 356.68x245.02x26.6mm

Weight • 2.5kg ±5%
