Panel Size |
27" |
|
Active Display Area (mm) |
596.736 (H) x 335.664 (V) |
|
Curvature |
Flat |
|
Panel Type |
Rapid IPS |
|
Panel Resolution |
Normal: 3840 x 2160 (UHD)
Dual Mode: 1920 x 1080 (FHD) |
|
Pixel Pitch (H x V) |
0.1554(H) x 0.1554(V) |
|
Aspect Ratio |
16:9 |
|
Brightness (nits) |
SDR: 400 cd/m2 (Typ.)
HDR: 400 cd/m2 (Peak) |
|
Contrast Ratio |
1000:1 (Typ.) |
|
DCR |
100000000:1 |
|
Signal Frequency |
Normal: 146.9~354.5KHz(H) / 48~160Hz(V)
Dual Mode: 146.9~356.6KHz(H) / 48~320Hz(V) |
|
ACTIVATED RANGE |
Normal: 48~160Hz
Dual Mode: 48~320Hz |
|
Refresh Rate |
Normal: 160Hz
Dual Mode: 320Hz |
|
Response time |
0.5ms (GtG, Min.) |
|
DYNAMIC REFRESH RATE TECHNOLOGY |
Adaptive-Sync |
|
HDR Support |
VESA DisplayHDR 400 |
|
Video ports |
1 x DisplayPort 1.4a (HBR3)
2 x HDMI™ 2.1 (4K@160Hz) |
|
USB ports |
2 x USB 2.0 Type-A
1 x USB 2.0 Type-B |
|
Audio ports |
1x Headphone-out |
|
Viewing Angle |
178° (H) / 178° (V) |
|
Adobe RGB / DCI-P3 / sRGB |
88% / 93% / 131% (CIE1976 Standard) |
|
Surface Treatment |
Anti-glare |
|
Display Colors |
1.07B, 10 bits (8 bits + FRC) |
|
Console Mode |
Supported Resolution & Refresh Rate:
1080p: 60Hz and 120Hz
1440p: 60Hz and 120Hz
2160p: 60Hz and 120Hz
HDMI™ CEC: Supported
VRR: PS5 and Xbox Supported |
|
Power Type |
Internal Power Board |
|
Power Input |
100~240V, 50/60Hz |
|
Adjustment (Tilt) |
-5° ~ 20° |
|
Adjustment (Swivel) |
-30° ~ 30° |
|
Adjustment (Pivot) |
-90° ~ 90° |
|
Adjustment (Height) |
0~130 mm |
|
Kensington Lock |
Yes |
|
VESA Mounting |
100 x 100 mm |
|
Dimension with Stand (W x D x H) |
613.5 x 227.9 x 536.3mm
(24.1 x 8.9 x 21.1 inch) |
|
Dimension without Stand (W x D x H) |
613.5 x 54.6 x 365.4mm
(24.1 x 2.1 x 14.3 inch) |
|
Weight (NW / GW) |
7.4 kg (16.3lbs) / 10 kg (22 lbs) |
|
Carton Dimension (W X D X H) |
840 x 148 x 475mm
(33 x 5.8 x 18.7 inch) |
|
Accessories |
1x DisplayPort Cable (1.4a), 1x USB Type-B to A Cable, 1x Power Cord (C13), 1x Quick Guide, 4x Stand Screw |
|
Note |
HDMI™: Normal(UHD) : 3840 x 2160 (Up to 160Hz)
Dual(FHD) : 1920 x 1080 (Up to 320Hz)
DisplayPort: Normal(UHD) : 3840 x 2160 (Up to 160Hz)
Dual(FHD) : 1920 x 1080 (Up to 320Hz)
Support: HDMI™ CEC, PIP/PBP; Non Support: KVM |
|
