CPU |
|
• |
Intel® Core™ 2 Duo
Processor T8100 / T8300 / T9300 / T9500 |
|
|
Core Logic |
|
|
Display |
| • |
17" TFT LCD WSXGA+/GT (1680x1050) |
| • |
17" TFT LCD WUXGA/GT (1920x1200) |
|
|
Memory |
|
• |
Supports Dual Channel
DDRII SDRAM |
|
• |
64-bit wide per channel |
|
• |
Two 200Pins SODIMM sockets |
|
• |
Supports for DDRII at 533MHz and
667MHz |
|
• |
Expandable Memory up to 4GB, depends
on 512MB/1GB/2GB SODIMM Module |
|
• |
(Option) Intel® Turbo Memory, 512MB/1GB |
|
|
Video Controller |
|
• |
nVIDIA®
GeForce® Go 8800GTX |
|
• |
512MB DDRIII Video ram on board |
|
• |
Support PCI-E*16 |
|
• |
MS Directx®9.0
compatible |
|
• |
MXM-IV |
|
|
• |
nVIDIA® GeForce®
8700M GT |
|
• |
512MB DDRIII Video ram on board |
|
• |
Support PCI-E*16 |
|
• |
MS Directx®10
compatible |
|
• |
MXM-III |
|
• |
Support HDCP |
|
|
|
Storage |
|
• |
1x changeable 2.5"
9.5mm(H), SATA HDD |
|
• |
1x changeable 12.7mm(H) Combo /
DVD-Dual |
|
|
Keyboard |
|
• |
Full size keyboard, Multi
language support |
|
• |
Built-in Touch pad with scrolling
function |
|
|
Sound System |
|
• |
Intel® High
definition audio interface |
|
• |
3D stereo enhanced sound system |
|
• |
SRS WOW Surround Sound Technolgy
inside |
|
• |
Compatible Sound-Blaster PRO™ |
|
• |
S/PDIF Digital output 7.1CH |
|
• |
1x Built-in Microphone |
|
• |
2x Built-in Speakers,1.5W |
|
• |
1x Built-in woofer 2W |
|
|
I/O Ports |
|
• |
4x USB 2.0 ports |
|
• |
1x DVI output (support Dual link) |
|
• |
1x Headphone jack |
|
• |
1x Microphone jack |
|
• |
1x Line in jack |
|
• |
1x S/PDIF Output jack |
|
• |
1x COM port |
|
• |
1x RJ-45 jack |
|
• |
1x RJ-11 jack |
|
• |
1x IEEE 1394 |
|
• |
1x TV out |
|
• |
1x RF-in jack |
|
• |
1x DC In jack |
|
• |
1x CIR for TV remote controller |
|
|
Slots |
|
• |
1x ExpressCard/54(34) slot |
|
• |
1x Mini-card slot (TV Tuner / Turbo
memory) |
|
• |
1x Mini-PCI socket (WLAN) |
|
• |
7-in-1 Card Reader (MMC/RSMMC/MS/MS
Pro/MS Duo/SD/Mini-SD) |
|
|
Communication |
|
• |
56K MDC Azalia Modem with
V.90&V.92 compliant |
|
• |
Built-in Gigabit Ethernet LAN |
|
• |
(Option) Intel® Wireless
LAN WiFi Link 4965AGN with MiniCard, PCI-E interface |
|
• |
1.3M pixel video
camera module with USB interface |
|
|
Power |
|
• |
Full Range 120W AC adapter
- AC input 100~240V, 50~60Hz, DC output 20V, 6A |
|
• |
Removable 8 cells smart Lithium-lon
battery pack, 4.4Ah |
|
|
Security |
|
• |
BIOS password |
|
• |
Kensington® Lock |
|
• |
(Factory Option) Fingerprint
Sensor |
|
|
O.S. |
|
• |
Windows® XP |
|
• |
Windows®VISTA Premium (64
bit) |
|
|
Dimension |
|
• |
397(W) x 284(D) x 22 ~
44(H)mm |
|
• |
3.95Kg with 8 cells Battery |
|
