Specification / Features on Clevo D901C Notebook
|
|
|
|
|
| |
| |
 |
 |
|
Features: |
- 17" WSXGA 1680 x 1050 Display
- Intel® P965 + ICH8-R Chipset Mainboard
- Support Intel® Core™2 Duo 800FSB CPU
- 2 x NVIDIA® GeForce Go 8800GTX 512MB Video
- Built-in 2.0 Mega Pixel Webcam
|
|
|
|
|
CPU |
|
• |
Intel® Core™ 2 Duo
Processor E6300/E6400
(1.86/2.13GHz, 65nm, FSB1066, 2MB L2 cache, LGA775) |
|
• |
Intel®
Core™ 2 Duo Processor E6600/E6700
(2.4/2.67GHz, 65nm, FSB1066, 4MB L2 cache, LGA775) |
|
• |
Intel®
Core™ 2 Duo Processor E6550/E6850
(2.33/3.0GHz, 65nm, FSB1066/FSB1333, 4MB L2 cache, LGA775) |
|
• |
Intel®
Core™ 2 Quad Processor Q6600/6700
(2.4/2.66GHz, G0 Stepping 65nm, FSB1066, 8MB L2 cache, LGA775) |
|
• |
Intel®
Core™ 2 Extreme Processor X6800
(2.93GHz, 65nm, FSB1066, 4MB L2 cache, LGA775) |
|
• |
For Quad
Core Support you need a specific version |
|
|
Core Logic |
|
|
Display |
|
• |
17.1" WSXGA+ (1680x1050) |
|
• |
17.1" WUXGA (1920x1200) TFT LCD |
|
|
Memory |
|
• |
64-bit wide DDRII data channel |
|
• |
Two
200pin SODIMM sockets, supporting DDRII 533/667/800 |
|
• |
Expandable Memory up to 4GB, based on 512/1024/2048MB SODIMM Module |
|
|
Video Controller |
|
• |
nVIDIA® GeForce® 8800M GTX,
MXM-IV Modular |
|
• |
512MB GDDRIII Video RAM on board, support PCI-E*16 |
|
• |
MS
DirectX® 10 compatible |
|
• |
HDCP
support |
|
|
|
Storage |
|
• |
1x changeable 12.7mm(H) DVD-Dual |
|
• |
3x
changeable 9.5mm(H), SATAII HDD(5400RPM/7200RPM, RAID 0/1/5) |
|
• |
(Option)
Blu-Ray Readable / Writable |
|
• |
(Option) HD-DVD Readable /Writable |
|
• |
(Option)
1x external USB 1.44MB Floppy Disk Drive |
|
|
Keyboard |
|
• |
Full size keyboard with Numeric pad,
Multi-Language support |
|
• |
Built-in
Touchpad with scrolling function |
|
|
Sound System |
|
• |
UAA (Universal Audio Architecture) |
|
• |
Integrated Azalia compliant interface |
|
• |
S/PDIF
Digital output |
|
• |
1x
Built-in Microphone |
|
• |
4x
Built-in Speakers |
|
|
I/O Ports |
|
• |
4x USB 2.0 ports |
|
• |
1x Mini
IEEE 1394a port |
|
• |
1x
S-Video out jack for TV output & HDTV output |
|
• |
1x
External CRT monitor output |
|
• |
1x DVI
output |
|
• |
1x
Headphone jack |
|
• |
1x
Microphone jack |
|
• |
1x S/PDIF
output jack |
|
• |
1x RJ-45
jack for 10M/100M Fast Ethernet |
|
• |
1x RJ-11
jack for Plug & Play Fax/Modem |
|
• |
1x
Line-in jack |
|
• |
1x DC-In
jack |
|
• |
1x CATV
input jack (Functional option with TV-Tuner module) |
|
• |
1x
S-Video in jack for Internal TV-Tuner (Functional option with
TV-Tuner module) |
|
|
Slots |
|
• |
1x New Card (34/54 pin) socket
(support USB&PCI-E interface) |
|
• |
1x
Mini-card socket (support USB&PCI-E interface), it's for WLAN |
|
• |
1x Mini-PCI
socket, for TV-Tuner module |
|
• |
Embedded
7-in-1 Card Reader (MS/MS Pro/MS Duo/MS Pro Duo/SD/Mini-SD/MMC) |
|
|
Communication |
|
• |
56K MDC Azalia Modem with V.90 & V.92
compliant |
|
• |
Gigabit
LAN on board |
|
• |
(Option)
Intel® 802.11a/b/g, PCI-E interface, |
|
• |
(Option)
Intel® Wireless WiFi 4965AGN |
|
• |
(Option)
Bluetooth™ ClassII V2.0, USB interface |
|
• |
(Factory
Option) 1.3M/2.0M pixel video camera module |
|
|
Power |
|
• |
Full Range 220W AC adapter - AC input
100~240V, 47~63Hz, DC output 20V, 11A |
|
• |
Main
battery changeable 12-cell smart Li-Ion pack, 6600mAh |
|
|
Security |
|
|
O.S. |
|
• |
Windows® XP |
|
• |
Windows®
VISTA™ Premium |
|
|
Dimension |
|
• |
397(W) x 298(D) x 51~60(H)mm |
|
• |
5.4Kg
with 12 cells Battery |
|
|
Options |
|
• |
DVD Dual drive module |
|
• |
Wireless
LAN (Mini-card) module, PCI-E interface |
|
• |
Bluetooth™ module, USB interface |
|
• |
TV-Tuner
module, Mini-PCI interface |
|
• |
Blu-Ray
& HD-DVD Drive Module |
|
• |
(Factory
Option) 1.3M/2.0M pixel video camera module |
|
|
**The specification in
gray are not available yet.
**The content is subject to change without notice. Other brand and
product names are trademarks and/or registered trademarks of their
respective companies.
**Battery Life may vary depending on applications and configuration.
**Version: 2007.11 |
|
|
*** This specification is subject to change without notice. Please look up manufacture specification for detail reference.
We are not responsible for typo or graphical errors. All typographical errors are subject to correction.***
