Processor |
Supports Intel® Core™2 Duo
Mobile 800FSB CPU
T8300 / T9300 / T9500 |
|
Chipset |
Intel® PM965 + ICH8-M |
|
Graphics & Video Module
|
NVIDIA® Mobile 8600GT 512MB graphic memory |
|
Main Memory |
DDR2 533/667 SO-DIMM x 2 slots, Max: 4GB |
|
Display |
15.4" WXGA (1280x800), WXGA+ (1440x900), or WSXGA+
(1680x1050) |
|
PC Cards Slot
|
- PCI Express card x1 |
|
Card Reader |
SD/MMC/MS/MS-Pro 4-in-1 Card Reader |
|
Hard Disk Drive
|
Supports SATA HDD |
|
Optical Drive
|
Supports Super-Multi DVD & CD Burner Drive |
|
LAN/Modem |
Gigabit LAN + 56K Modem:
- Broadcom 5786 Gigabit LAN
- Internal Modem with MDC 1.5 solution V.92/56K bps; V.90/56K bps |
|
Wireless LAN |
Supports 802.11g Wireless Network Adapter |
|
Built-in CMOS Camera
|
Built-in 2.0 Mega Pixels
- Fix-Focus
- Face Detect Function |
|
Security Feature |
Built-in Fingerprint Sensor |
|
I/O Ports |
| • |
Monitor ( VGA ) : 15 pin D-Sub x 1 |
| • |
S-Video out x 1 + S-Video in x 1 |
| • |
USB 2.0 : 4 |
| • |
IEEE 1394 : 1 |
| • |
MIC-in : 1 |
| • |
Headphone out : 1 |
| • |
DC-in jack : 1 |
| • |
RJ11 : 1 |
| • |
RJ45 : 1 |
| • |
Express Card 34/54mm x 1 |
| • |
Kingston lock x 1 |
| • |
RF in x 1 |
|
|
Audio |
- Realtek ALC268
- 2 channel HD Audio
- Compliant with Universal Audio Architecture
- 95dB SNR DACs / 90dB SNR ADCs can meet Vista Premium requirement
- Microphone-in and headphone-out
- Internal Microphone
- Two stereo 1.5W speakers with chamber
- Volume control: Hot-key control for Windows |
|
Short-Cut Keys
|
• Control button for short-Cut key
functions
- 1 WWW (Explorer) key
- 1 E-mail (Outlook) key
• Control buttons for Wow AV
- Wow Video -- four mode: Movie, Photo, Office, Nature
- Wow Audio -- need to define
• Control buttons for Smart Charging
- Smart Charging
• Control buttons for Power USB
- Power USB (Workable in system off mode) |
|
Battery Pack & Life
|
- 6-cell Li-On Battery Pack |
|
AC Adapter |
19V DC, 90W/Input: 100~240V AC, 50/60Hz
universal |
|
Dimension |
13.97 (W) x 10.11 (D) x 1.38~1.47 (H)
(inch) |
|
Weight |
6.18 lbs (complete system + 9 cell
battery) |
