Processor |
Intel Conroe / Core 2 Duo Conroe E4300
(1.86G), E6300(1.86G), E6400(2.13G), E6600(2.4G), E6700(2.66G),
X6800(2.93G) Interface |
|
OS Support |
Microsoft® Vista Ultimate, Premium & Basic
Microsoft® Windows® XP Pro/Home |
|
Chipset |
Intel® 945G + ICH7M |
|
Main Memory |
DDR2 533/667 SO-DIMM x 2 slots |
|
Display |
15.4" WSXGA+ ( 1680 x 1050 ) TFT LCD
w/ Color Shine and Crystal Shine Technology |
|
Video Graphics |
nVidia 8600M GT 512MB Video with Turbo
Cache technology supports up to about 1.2GB graphic memory |
|
Hard Disk Drive
|
- 2.5" 9.5mm HDD (SATA)
- Supported capacities of 80/100/120/160GB
- 5,400/7,200 RPM |
|
Optical Drive
|
Built-in
DVD-RW SM, 8x/6x, 2.4x/2.4x |
|
Communications |
- On-board 10/100/1000 Mbps LAN
- On-board Azalia Modem
- Wireless 802.11 a/b/g adapter |
|
Card Reader |
8-in-1: SD/Mini-SD/MMC/XD/MS/MS Pro/MSDuo/MS-Pro-Duo |
|
LED Status Indicator |
- Power-On/Suspend (Blue)
- Battery Charging/full/low (Orange)
- E-mail (Blue)
- WLAN Indicator/Bluetooth indicator (Blue)
- Storage Device Access (Blue)
- Num Lock (Blue)
- Caps Lock (Blue)
- Camera (Blue) |
|
Interface |
- 1 VGA Port for External Display
- 1 HDMI
- 1 Headphone-out jack (SPDIF)
- 1 Microphone-in jack
- 1 RJ11 Modem jack for phone line
- 1 RJ45 LAN jack for LAN insert
- 3 USB 2.0 ports
- 1 TV-out (S-Video/Composite)
- 1 IEE 1394
- 1 E-SATA
- 1 MCX Connector for TV-Tuner (Optional)
- 1 Express Card Slot (34/54 support)
- 1 8-in-1 Card Reader
- Built-in Camera (2.0MP)
- Built-in Bluetooth EDR 2.0
- 2 Built-in Microphones
- Built-In Speakers (1.5w)
- Built-in Touch Pad pointing device(2 buttons)
- Built-in Finger Printer Reader |
|
Hoy Keys |
Instant Launch
Keys
- 5 Buttons: Power, Power4Gear, Touchpad Lock, E-mail, Internet
Function Keys
- Fn+F1 Suspend Switch
- Fn+F2 Wireless LAN on/off
- Fn+F3 E-mail
- Fn+F4 Internet
- Fn+F5 Brightness down
- Fn+F6 Brightness up
- Fn+F7 LCD on/off
- Fn+F8 LCD/External Display switch display
- Fn+F9 Touch Pad Lock
- Fn+F10 Volume on/mute
- Fn+F11 Volume down
- Fn+F12 Volume up
- Fn+Ins Numberic Key Pad on/off
- Fn+Del Scroll Lock on/off
- Fn+Space Power 4 Gear |
|
Battery Pack & Life
|
- Primary: 6-cell 4,800mAh Battery, 53Wh
- Smart Battery: Battery Charging Time of 4hrs/2.5hrs (System On/Off) to
95% |
|
AC Adapter |
Output: 19V DC, 4.73A, 90W
Input: 100~240V AC, 50/60Hz universal |
|
Keyboard |
- 19mm Full-Size With MS-Windows Function
Keys/Add Vista K/B Start Button (CBB) |
|
Dimensions & Weight |
- 14.4 x 10.5 x 1.3~1.7 (inch)
- 6.8 lbs (complete system + 6 cell battery) |
|
Accessories |
Carrying Bag |
