CPU |
| • |
Intel®
Core™
2 Duo
processor T9400/T9600
(2.53/2.80GHz, 45nm, FSB1066, 6MB L2 cache,
478uFC-PGA, Socket P) |
| • |
Intel®
Core™
2 Duo processor
P9500
(2.53GHz, 45nm, FSB1066, 6MB L2 cache, 478uFC-PGA,
Socket P) |
| • |
Intel®
Core™
2 Duo
processor P8400/P8600
(2.26/2.40GHz, 45nm, FSB1066, 3MB L2 cache,
478uFC-PGA, Socket P) |
|
|
Core
Logic |
|
|
Display |
| • |
15.4" WXGA(1280x800)
TFT LCD |
|
|
Memory |
| • |
Two 64-bit wide DDRIII
data channels |
| • |
Two 204 pins SODIMM
sockets, support DDRIII 1066MHz |
| • |
Expandable memory up
to 4GB, depends on 1GB/2GB SODIMM Module |
|
|
Video
Controller |
| • |
nVIDIA® GeForce®
GTX 260M GT |
| • |
1GB GDDRIII
Video RAM on board |
| • |
Support PCI-E
x16 |
| • |
Microsoft®
DirectX® 10 Compatible |
| • |
MXM TypeIII |
| • |
Support HDCP |
|
|
|
Storage |
| • |
One changeable
12.7mm(H) Combo / Super-Multi / Blu-ray ODD, SATA
interface |
| • |
One changeable 2.5"
9.5mm(H) HDD, SATA interface |
| • |
(Option) Intel®
Turbo
memory 2GB MiniCard with PCIe interface |
|
|
Keyboard |
| • |
Multi language |
| • |
Built-in Touch pad
with scrolling function |
|
|
Sound
System |
| • |
High Definition Audio
interface |
| • |
3D stereo enhanced
sound system |
| • |
S/PDIF digital output |
| • |
Sound-Blaster PRO™
compatible |
| • |
Built-in microphone |
| • |
Built-in two speakers |
|
|
I/O
Ports |
| • |
4x USB 2.0 ports |
| • |
1x eSATA port (VISTA
only) |
| • |
1x IEEE 1394a port |
| • |
1x DVI-I output port
(no HDCP support) |
| • |
1x HDMI output port |
| • |
1x headphone jack |
| • |
1x microphone jack |
| • |
1x S/PDIF output jack |
| • |
1x RJ-11 jack |
| • |
1x RJ-45 jack |
| • |
1x DC-in jack |
|
|
Card
Reader |
| • |
7-in-1 Card Reader (MMC/RSMMC/SD/Mini-SD/MS/MS
Pro/MS Duo) |
|
|
Slots |
| • |
One ExpressCard
/54(/34) slot |
| • |
Two MiniCard slots
with USB & PCIe interface (1st for WLAN module, 2nd
for Intel®
Turbo memory / 3.5G module) |
|
|
Communication |
| • |
56K / FAX modem |
| • |
Built-in 10/100/1000MB
Base-TX Ethernet LAN |
| • |
Intel® WiFi
Link 5300 3x3 802.11AGN MiniCard with PCIe interface |
|
|
Power |
| • |
Full Range AC adapter
120W, AC in 100~240V, 50~60Hz, DC output:20V, 6.0A |
| • |
Removable 8 cells
smart Lithium-Ion battery pack, 4400mAh |
| • |
Battery life > 130
minutes (with nVIDIA®
GeForce®
Go 9600M GS) |
|
|
Security |
| • |
Kensington® Lock |
| • |
(Factory Option)
Fingerprint security |
|
|
O.S. |
| • |
Winodws®
VISTA™
(SP1) |
| • |
Winodws®
XP™
(SP3) |
| • |
Winodws®
VISTA™
Premium (64-bit) logo |
|
|
Dimension |
| • |
14.33"(W) x 10.61"(D)
x 1.14"~1.61"(H) (364(W) x 269.5(D) x
29~41(H)mm) |
| • |
3.2kg with 8 cells
battery and ODD |
|
